Product Details:
Payment & Shipping Terms:
|
| Insulation Material: | XLPE | Type: | Low Voltage |
|---|---|---|---|
| Application: | Solar Panel System | Conductor Material: | Copper |
| Jacket: | Rubber | Product Name: | Twin Core 6mm DC Solar Cable |
| Color: | Red/Black | Certificate: | TUV,CE |
| Rated Voltage: | AC 600/1000V DC 1000/1800V | Core: | 1 Core/2 Core |
| Cross-section: | 1.5/2.5/4/6/10 Mm2 | Rated Temp: | -40℃-+90℃ |
| Rated Current: | 20-95A | Weathering Resistance: | 4.97Ω |
| Finished Cable O.d: | 5.35+-0.1mm | Port: | Ningbo/Shanghai |
| High Light: | CE TUV Solar Panel Cords,6mm DC Solar Cable,6mm Solar Panel Cords |
||
Suntree Twin Core 6mm DC Solar Cable Approved CE ,TUV
1. Dual wall insulation.Electron beam cross-linked
2. Excellent resistance to UV,oil,greases,oxygen and ozone
3. Excellent resistance to abrasion
4. Halogen free, flame retardant,low toxicity
5. Excellent flexibility and stripping performance
6. High current carring capacity
7. TUV approved
|
Single Core
|
Cross section mm²
|
Strand design No.x ø(mm)
|
Conductor diameter mm
|
Conductor diameter Ω /km
|
Outer diameter mm
|
|
PV-1*1.5 mm²
|
1.5
|
30x ø 0.25
|
1.6
|
13.9
|
4.5
|
|
PV-1*2.5 mm²
|
2.5
|
48x ø 0.25
|
2.0
|
8.06
|
5.3
|
|
PV-1*4.0 mm²
|
4.0
|
56x ø 0.3
|
2.6
|
4.97
|
6.2
|
|
PV-1*6.0 mm²
|
6.0
|
81x ø 0.3
|
3.3
|
3.52
|
7.2
|
|
PV-1*10.0 mm²
|
10.0
|
200x ø0.25
|
4.4
|
2.12
|
8.3
|
|
PV-1*16 mm²
|
16.0
|
224x ø 0.3
|
5.2
|
1.95
|
9.5
|
|
Twins Core
|
|
|
|
|
|
|
PV-2*1.5 mm²
|
1.5
|
30x ø 0.25
|
1.6
|
13.9
|
5.80*9.30
|
|
PV-2*2.5 mm²
|
2.5
|
48x ø 0.25
|
2
|
8.06
|
6.20*9.90
|
|
PV-2*4.0 mm²
|
4
|
56x ø 0.3
|
2.6
|
4.97
|
6.90*11.30
|
